Seam Welding Equipment Air duct arc seam welding machine of
Resistance arc welding
| Welding diameter | Ø80~Ø300mm |
| Welding angle | 45° 90° 15° 60° |
| Weld thickness | Low carbon sheet steel:0.3~0.8mm |
| | Galvanized sheet steel:0.3~0.8mm |
| | Stainless steel sheet:0.3~0.6mm |
| Welding speed | 3~9m/min |
| Overlap | 6mm |
| Welding copper wire diameter | Ø2.0 mm |
| Cooling water flow rate | 0.4Mpa 8.5L/min |
compressed air
| 0.8Mpa 600L/min ≤25°C |
| Welding power | 50KVA |
| Net weight | 1.3T |
Seam Welding Equipment Air duct arc seam welding machine of Resistance arc welding
- Air duct arc seam welding machine
- Resistance arc welding
- Arc welding
- Air duct weiding
- Sheet metal welding
- Duct welder
- Vanitation pipe
Product of Seam Welding Equipment Air duct arc seam welding machine of Resistance arc welding
Air duct arc seam welding machine of Resistance arc welding
RF-80J-1 basic type pipe bending welding machine is suitable for
welding the outer arc of the stamping accessories of the land circular air duct.
The RF-80J-1 basic pipe bending welding machine adopts a welding
three-dimensional design frame, confirms the arc welding curve
point by point, and ensures the smooth movement of the welding
workpiece.
The equipment man-machine interface control, welding control unit
and other aspects are all independently developed and designed,
including welding current, speed and other important welding
elements to fully realize the digital display of the man-machine
interface. And according to the welding characteristics of
galvanized sheet steel, a unique welding curve is designed in
welding control, so that the professional needs of galvanized sheet
welding can be more reliably completed.
The RF-80J-1 basic elbow welding machine is used in conjunction
with the RF-80J-2 elbow welding machine, which can perfectly weld
arc welding products. This set of equipment can not only meet the
welding needs of stamped air ducts, but also work on the welding
needs of straight short products, making it widely used in
shipbuilding, industrial air ducts, pharmaceutical industries and
other fields. The RF-80J-1 basic mud tube welding machine can weld
light steel sheets, galvanized sheets and stainless steel sheets.
